Reliable Steam Generation for Advanced Laboratory Use

The water vapor generator is designed for simple and safe operation, featuring a unique vaporization structure that overcomes the common issues of traditional generators, such as unstable flow, difficult temperature control, and inconsistent vapor output.

It provides precise, continuous, and stable steam for a variety of applications, including steel corrosion testing, fuel cell testing, catalytic hydrothermal aging, fixed bed and fluidized bed reactions, biodegradation, and synthesis reactions.

Operating Requirements:

Environment: The generator operates effectively in environments with temperatures ranging from ambient to 60°C

and humidity levels up to 90% RH.

Power Supply: Requires a 220V AC external power supply and provides a 24VDC power source for calibration

instruments.

Laboratory Setup: Operates under standard laboratory conditions without the need for expensive fully

air-conditioned environments. The device requires only distilled water, 10 bar oil-free compressed air,

and 90-230VAC power.

Measurement Range: Works within a humidity range of 10-95% RH, suitable for calibrating cylindrical probe

transmitters (e.g., transmitters, handheld meters) and wall-mounted square transmitters (e.g., data loggers,

wall-mounted instruments).

Safety Considerations: Ensure that the internal vaporizer, sealed with PTFE, does not exceed a temperature

of 260°C. During high-flow experiments, set the vaporization temperature to at least 150°C to prevent the liquid

from not vaporizing properly. After high-flow operations, stop the liquid feed and set the vaporization

temperature to 0°C to avoid temperature overshoot. Avoid activating the heating switch without connecting the

heating tape.

This solution ensures that the water vapor generator delivers reliable, precise performance in a variety of

demanding applications while maintaining safety and ease of use.
